    50V 0.4A 20W EU POE injector, POE power supply ▼
      product:50V 0.4A 20W EU POE injector, POE power supply
        KRECO P/N:KRE024POE-500R400VG
        SPEC DOWNLOAD...
        More Catalogs...
        Request a Quote: sales@kreco.com.cn
        go to iPSKRE.com
Details:
50VDC 0.4A series External Wallmount POE adaptor, 50VDC 0.4A POE switch, AC/DC megabit POE adaptor, POE injector, Class II, Universal input, customized design
P/N: KRE-POE
Model Number: KRE024POE-500R400VG

General: 50VDC 400mA series Power Over Ethernet adapter









Input voltage: 100 to 240VAC
Input frequency range: 50 to 60Hz
input current: 400mA
No load input power (240V AC): 0.3W
Efficiency: 80% maximum
Inrush current (240V AC): 25A, cold 25°C




Power: 20W
DC output voltage: 50VDC
DC output current: 400mA
Ripple/noise: 100mV
Output voltage precision: 5%
Regulation: ±1% line, ±5% load




With LED indicator:
Fault :Led-Blinking
power on: Led-Red
Working: Led-Green
High reliability
Light and convenient plug-in
High efficiency: consumption, meet US Energy start/CEC/AS/MEPS/EUP/ERP

2 Year warranty
ROHS Compliant
802.3af or 802.3at standard
Wide Input Voltage 90 to 264VAC,50 to 60Hz
Data Rate:10/100Mbps




Operating humidity: 10 to 95% RH
Storage temperature: -20 to 65°C
Storage humidity: 10 to 95% RH
Operating temperature: 0 to 40°C




Thermal shutdown capability
Over-current protection
Over-voltage protection
Over temperature protection
Short-circuit protection




MTBF: meet MIL-HDBK-217F over 50,000hrs, full load, 25°C
Burn-in: 100% full load, 40°C, 4hrs minimum
Leakage current: 0.25mA maximum at 264V AC
Withstanding voltage: 3kV 1minute 10mA max, between primary and secondary




EN55022 Class B
CNS13438 Class B
FCC Part15 Class B
CISPR22 Class B
EN55024/A1:2001
IEC61000-4-11; IEC61000-4-6
IEC61000-4-5; IEC61000-4-4
IEC61000-4-3; IEC61000-4-2
GB9254-1998/GB17625.1-2003
AS/NZS3548, AS/NZS4251.1 class B




CE(Low Voltage Directive)
UL1310, GB4943-2001
EN60950:2009; EN60065
PSE IEC60950, EN60065
AS/NZS 60950:2000, AS/NZS60065









PE bag
Individual white box
Carton dimensions: 470x350x240mm
Quantity: 100 pieces per carton
Gross weight: 9kg maximum
