17. What should be noticed when installing a power supply?
Add time:2017-09-29    Click:491

What should be noticed when installing a power supply in vertical and horizontal directions?


Most small wattage and fanless power supplies are mainly installed in the horizontal position. If you have to install it vertically because of mechanical limitation, you should consider the output derating due to the heat concern. The temperature derating curve can be found on the spec sheet. Regarding the power supplies with built-in fan or the application has forced cooling system, vertical and horizontal installations have less difference.
