KRECO Group - Power Solutions Business Division (www.iPSKRE.com)
Details:
DC12V, 15.4W Series Desktop POE Splitter, Megabit POE adaptor, POE injector, Class B
P/N:
KRE-POED05
MODEL NUMBER: KRE-1201280D




100% full load testing and stable performance, 40°C, 4 hours minimum
MTBF: meet MIL-HDBK-217F over 50K hours, full load and 25°C
Leakage current: 0.25mA maximum at 264V AC
Withstanding voltage: (3kV 1 minute 10mA maximum, between primary and secondary)




Input voltages: POE input
Output Power: 15.4W
DC output voltages: 12V DC
DC output current: 1,280mA
Output voltage precision:5%
Ripple and noise: 100 mV
Regulation: ±1% line, ±5% load
POE Type: support both Mid-Span and End-Span




Media: 100Base-TX(≤100,Catalogue 5Cable)
Protocol: IEEE 802.3I; IEEE802.3U; IEEE802.3x Flow Control; IEEE 802.1af DTE Power via MDI
Customized designs are accepted
Design time: 5 working days maximum
Applications: printer, POS machine, consumer product, electronic product and more
General: 15.4W series Power Over Ethernet adaptor for your collection
DC input, Can supply different countries use.
Anti-interference good intensity, reliable performance is high.
Insulation performance is good, resistance to electric high strength.
POE Switch power performance dc Ripple small, high efficiency, energy saving.
The products have passed international safety and regulatory requirements.
With short circuit protection, overload protection, over-current protection function, use more safety.




Thermal shutdown capability
Over-voltage protection (OVP)
Short-circuit protection (SCP)
Over-current protection (OCP)




UL, CUL, ETL, CETL, GS, CE, TUV, LVD, EMC, FCC, CCC, PSE, CB, C-tick, SAA, PCT, ROHS, PAHS and so on




EN55022 class B
FCC part15 class B
AS/NZS3548, AS/NZS4251.1 class B
CISPR22 class B
EN55024/A1:2001
IEC61000-4-2/3/4/5//6/11
GB9254-1998/GB17625.1-2003
CNS13438 class B




Light and convenient plug in
2 Year warranty
ROHS Compliant
With LED indicator:
power on: Led-Red
Working: Led-Green
Fault: Led-Blinking
High reliability
802.3af or 802.3at standard
Data Rate:10/100/1,000Mbps




Oprating temperature:0 to 55℃
Storage temperature:-20 to 75℃
Operating humidity: 10 to 95% RH
Storage humidity: 10 to 95% RH









NO. Type Shape Shape NO. Type  Shape
1 UL
Plug
2 UK
Plug
3 GS
Plug
4 Korea
Plug
5 Australia
Plug
6 Italy
Plug
7 China
Plug
8 Denmark
Plug
9 Argentina
Plug
10 Switzerland
Plug
11 Brazil
Plug
12 Israel
Plug
13 Japan
Plug
14 South Africa
Plug
